Crabbs Branch Storm Hydrograph

View Original Image at Full Size

Stream stage and precipitation during a rainfall event that occured on Sept. 26-28, 2008. The stream stage rises rapidly, indcative of the flashy runoff from impervious areas of the watershed. However, the stream stage falls slowly due to the influence of the stormwater management pond in the Crabbs Branch headwaters, which releases water into the stream over a long period of time.

Image 23952 is a 572 by 911 pixel JPEG
Uploaded: May7 10

Last Modified: 2010-05-07 15:44:11
Permanent URL:

The file is referred to in 1 page
•Coastal Resources, Inc., 2009. RC-74 Stream Study: Crabbs Branch Conceptual Design Report. Annapolis, MD. 77 p.
