Lab 5: Evidence of Recent Change
The lab activity described here was developed by Erin Bardar and Candace Dunlap of TERC for the EarthLabs project.Use the button at the right to navigate to the student activity pages for this lab. To open the student pages in a new tab or window, right-click (control-click on a Mac) the "Open the Student Activity" button and choose "Open Link in New Window" or "Open Link in New Tab."
Investigation Summary and Learning Objectives
In this lab, students will explore evidence of recent change in the cryosphere. In Part A, they will use an online interactive to visually explore how six Alaskan glaciers have changed over the last hundred years. They will also use image processing software to measure how much area a glacier in the Himalayas has lost over time due to rising temperatures. In Part B, students will study recent trends in Arctic sea ice extent. In Part C, they will explore the ice-albedo feedback effect and think about causal connections between climate and the cryosphere.
After completing this investigation, students will be able to:
- describe evidence of recent changes observed in glacial ice;
- measure changes in glacial area and extent using ImageJ;
- describe recent trends in sea ice extent;
- explain how the ice-albedo feedback loop works; and
- explain the difference between positive and negative feedback mechanisms.
For more information about the topic, read the section titled Background Information under Additional Resources below.
Activity Overview and Teaching Materials
In Part A: Students first visually examine photograph pairs to see how glaciers and the surrounding landscape change over time. They then use ImageJ to measure the area lost by the Gangotri Glacier in India since 1780. NOTE: All student computers will need to have ImageJ installed before beginning Part C of this lab.
ImageJ is free public domain image processing software developed at the National Institutes of Health. Its power and flexibility allow it to be used as a research tool by scientists in many disciplines, from medicine to astronomy. Installers are available for Windows, MacOS and OSX, and Linux.
You can use ImageJ to display, annotate, edit, calibrate, measure, analyze, process, print, and save raster (row and column) image data. It reads most common raster image formats as well as raw data files in text format, such as from spreadsheets. ImageJ also supports stacks - multiple images in a single window - for animation and analysis.
To Download and Install ImageJ:
Go to the ImageJ Download page, and download and install the application for your operating system.
Click the ImageJ Download page and it will open in a new window. Click the link that appears directly below the name of your computer's operating system (e.g. Mac, Linux, Windows). This action will transfer a compressed file of the software to your computer. Your browser should automatically expand the file, creating an ImageJ folder on your computer's hard drive.
For more details, or if you have problems running the application, access ImageJ's Installation Instructions then select your operating system.
Updating ImageJ Software
Double-click the ImageJ icon to launch the application and choose Help > Update ImageJ.... A window will appear, telling you the version you are currently running and a list of upgrade versions. Choose the version you want to upgrade to (usually the most recent, or default version) and click OK. After the update downloads, re-launch ImageJ to run the new version. NOTE: Some users have reported problems updating ImageJ in certain versions of Windows. To fix this problem, you will need to manually update ImageJ.
- Right-click the link at right to download the ij.jar file. Be sure to save it as simply ij.jar. ij.jar (Jar Archive 1.4MB Feb8 10)
- When prompted where to save the file, navigate to the ImageJ folder and save the file there. Replace the existing ij.jar file.
- For most installations, the ImageJ folder will be in the Program Files directory on your hard drive. The path to the ImageJ folder is c:\Program Files\ImageJ.
The ImageJ Toolbar
The ImageJ toolbar contains both built-in and customized tools for manipulating images. Most of the tools are similar to those used in other graphics programs.
Time estimate: 50-75 minutes
In Part B: Students study recent trends in Arctic sea ice extent and revisit the topic of albedo.
Time estimate: 25-50 minutes
In Part C: Students Students learn about the concept of albedo and the ice-albedo feedback effect using the online interactive Earth's Albedo and Global Warming. They will also do a "Connection Circles" activity to explore the concept of feedback loops.
Time estimate: 50 minutes
- Stop and Think Questions (PDF (Acrobat (PDF) 50kB May21 13) and Word (Microsoft Word 36kB May21 13))
- Suggested Answers (Microsoft Word 34kB May21 13) to Stop and Think Questions
Teaching Notes and Tips
In Part A: Make sure ImageJ is installed on all student computers before beginning the lab. Practice the exercise yourself before teaching so that you are prepared to answer student questions during the lab.
In Part B: To be determined through testing.
In Part C: Practice the Connection Circle before doing the activity with students.
- Assess student understanding of topics addressed in this investigation by grading their responses to the Stop and Think questions.
- Teachers may want to collect and grade the graphing activities or weather observation forms.
- Written Test for Lab 5 (Microsoft Word 2007 (.docx) 102kB May21 13) (Test key (Microsoft Word 2007 (.docx) 213kB May21 13))
State and National Science Teaching Standards
Developer will correlate activity to standards listed at this site:National Science Education Standards (SRI)
- Visit the National Snow and Ice Data Center's website for background reading about Interactions and Feedback in the cryosphere.
- For additional background information about the ice-albedo feedback loop, read the Windows to the Universe article Ice-Albedo Feedback: How Melting Ice Causes More Ice to Melt.
- For additional information and beautiful and powerful imagery of how climate change is affecting Greenland, consider showing all or parts of the NOVA video Extreme Ice. Approximate running time: 53 minutes.
- EET Chapter: Using NASA NEO and ImageJ to Explore the Role of Snow Cover in Shaping Climate: "In this chapter, you will investigate satellite images displaying land surface temperature, snow cover, and reflected shortwave radiation data from the NASA Earth Observation (NEO) website.
Download, explore, and animate these images using ImageJ, a public domain image analysis program from the National Institutes of Health (NIH). Then use the web-based analysis tools built into NEO to observe, graph, and analyze the relationship between the three variables."
