Nitrates and Phosphates and Algae, Oh My!
The lab activity described here was created by Erin Bardar of TERC for the EarthLabs project.
Activity Summary and Learning Objectives
Human-induced nutrient loading of the world's oceans has been linked to increased and prolonged algae blooms, sometimes with potentially deadly consequences. In this investigation, students will create their own algal blooms, analyze satellite images of chlorophyll concentrations in the Sea of Cortés, and learn about two alarming consequences of excessive algae growth-dead zones and harmful algae blooms (HABs).
After completing this investigation, students will be able to:
- understand the conditions required for algae growth;
- understand the factors that influence the occurrence and duration of algal blooms;
- interpret satellite images of chlorophyll concentrations (ocean color); and
- explain the potentially harmful consequences of algal blooms including dead zones.
Context for Use
In the previous investigation, Aquaculture, students learned that one of the drawbacks of coastal aquaculture facilities is the transfer of additional waste and nutrients to the surrounding water. In this investigation, students learn about other ways in which humans are increasing the nutrient content of coastal waters and about the ensuing consequences for land and sea. The investigation requires laboratory space and equipment, which should be procured ahead of time. For the laboratory portion of the investigation, students should be assigned to small groups of 3-5 students.
Activity Overview and Teaching Materials
In Part A, students make their own algal blooms and test what factors influence the occurrence and duration of the blooms. The following materials are needed for each group of 3-5 students:
- algal culture (available from a scientific or aquarium supplier or even from a classroom aquarium)
- water (fresh or salt depending on the type of algae)
- two 250-500 mL clear glass or plastic containers
- light source (sunny window will work)
- droppers or pipettes
- liquid plant fertilizer
- wax pencil, tape, or stickers to label containers
- microscope (10x or greater magnification)
In Part B, students use images and data from the Sea-viewing Wide Field-of-view Sensor (SeaWiFS) Project, to look for correlations between phytoplankton blooms in the Sea of Cortés and the addition of nutrients through agricultural runoff from the surrounding land. Students create a time-series animation of chlorophyll concentration over a two-year tie period. They also generate an area-averaged chlorophyll concentration data plot showing the average chlorophyll concentration in the Sea over the same two year time period. Both visualizations are produced using Giovanni Ocean Color Time-Series Online Visualization and Analysis Tool. The Giovanni tool requires the Java 2 Platform. For more detailed information about Giovanni's compatibility with your computer's operating system and internet browser, go to the Goddard Earth Sciences Data and Information Services Center website. A non-Java version is also available.
Students conclude Part B by reading the article Researchers discover direct link between agricultural runoff and massive algal blooms in the sea, which explains the connections between the algal blooms observed in the satellite data and agricultural runoff from Mexico's Yaqui Valley.
In Part C, students learn about dead zones and harmful algae blooms (HABs). They first look at the graphic Birth of a Dead Zone from Part 1 of the L.A. Times Series, Altered Oceans. They then read the Earth Policy Institute article, Dead Zones Increasing in World's Coastal Waters. To view the Altered Oceans multimedia graphics, student computers need to be equipped with the Adobe Flash Player.
The final portion of this investigation introduces students to HABs. They revisit the Altered Oceans series to view the graphic Harmful algae blooms and their consequences and read the story Dark Tides, Ill Winds.
- Activity Sheet (PDF (Acrobat (PDF) 35kB Jan28 08) and Word (Microsoft Word 24kB Jan28 08))
- Suggested Answers (Acrobat (PDF) 46kB Jan28 08)
Teaching Notes and Tips
Be sure to dispose of algal cultures responsibly. Do not allow students to pour cultures down the drain without treating them first. To prepare cultures for safe disposal, do one of the following. (1) Add bleach to the culture to make a 1% solution. Leave the bleached cultures to sit overnight and then pour down the drain with running water. (2) Bring the cultures to a boil in a microwave-safe container in a microwave oven. Although this may be accompanied by an unpleasant smell, it will not contaminate your microwave or make it unsafe for future food preparation.
Possible Extensions for Part A:
- Use more than one species of algae (grown separately) to compare the growth of different species under similar conditions.
- Add treatments to test the effect of temperature or salinity on algal growth. Create graphs of final cell density versus temperature or salinity.
You can assess student understanding of topics addressed in this Investigation by grading their responses to the Stop and Think questions.
State and National Science Teaching Standards
California Science Teaching Standards met by this activityDeveloper will correlate activity to standards in these documents:
Earth science content standards - Grades 9 to 12
Biology content standards (see Ecology) - Grades 9 to 12
Investigation and Experimentation Standards - Grades 9 to 12
Developer will correlate activity to standards in this document:PDF of Science and technology standards Earth science standards begin on page 112
Developer will correlate activity to standards in this document:Learning standards for science
Developer will correlate activity to standards in this document:North Carolina Standard Course of Study
Developer will correlate activity to standards in this document:Texas Essential Knowldege and Skills (TEKS)
Developer will correlate activity to standards listed at this site:National Science Education Standards (SRI)
- For background information about algal blooms, read the Wikipedia entry: Algal Blooms.
- For background information about dead zones, read the Wikipedia entry: Dead Zone (ecology).
- For background information about harmful algae blooms, visit The Harmful Algae Page, supported by a National Oceanic and Atmospheric Administration Center for Sponsored Coastal Ocean Research Coastal Ocean Program (NOAA/CSCOR/COP) grant.
- Eutrophication and dead zones also occur in bodies of fresh water such as Lake Erie. Check out the Environmental Protection Agency's informational page on the Lake Erie Dead Zone.
- Although the addition of fertilizer to the world's oceans is typically unintentional, some scientists believe that deliberate addition of certain types of fertilizer may help combat global warming. For more information about this topic, read the Science Daily article Marine Researchers Fertilize Southern Ocean To Study Climate Changes.
